Allow specifying environment variables when installing an engine plugin as a Swarm service by sirlatrom · Pull Request #38441 · moby/moby

sirlatrom · 2018-12-27T17:15:15Z

- What I did
I enabled specifying environment variables when installing a plugin through a Swarm service.

- How I did it

I added an Env []string field to the PluginSpec type by modifying its protobuf file, allowing environment variables (and values) to be specified when a plugin is to be installed as a Swarm service.
I added logic to transfer the environment variables to the resulting plugin task.

- How to verify it
a) Specify Env: []string{"MY_ENV_VAR=my-env-value"} in the TaskTemplate.PluginSpec object of the swarm.ServiceSpec when calling the service/create endpoint.
Example:

...
Env: []string{
    "policy-template={{ .ServiceName }},{{ .TaskImage }},{{ ServiceLabel \"com.docker.ucp.access.label\" }}",
...
},

b) The test TestServicePlugin in integration/service/plugin_test.go now covers the changed code.

- Description for the changelog

Allow specifying environment variables when installing an engine plugin as a Swarm service.

- A picture of a cute animal (not mandatory but encouraged)

codecov · 2018-12-27T19:59:45Z

Codecov Report

Merging #38441 into master will decrease coverage by 0.02%.
The diff coverage is 0%.

@@            Coverage Diff             @@
##           master   #38441      +/-   ##
==========================================
- Coverage   36.89%   36.87%   -0.03%
==========================================
  Files         613      613
  Lines       45421    45435      +14
==========================================
- Hits        16760    16754       -6
- Misses      26370    26389      +19
- Partials     2291     2292       +1

plugin/defs.go

sirlatrom · 2019-01-09T14:10:38Z

@thaJeztah I've incorporated your suggested change. I could not find any existing tests covering the WithSwarmService adjacent to my WithEnv function.

cpuguy83 · 2019-01-09T18:14:25Z

Can you add a test for this (or modify the swarm plugin create test?)

sirlatrom · 2019-01-09T20:11:42Z

@cpuguy Sure thing, thanks for the pointer, I'll see if I can add it to the right place in that test.

sirlatrom · 2019-01-10T16:42:57Z

@cpuguy83 Currently there's no way for the Docker engine to tell what tasks exist for a plugin Swarm service, since they are in a different namespace. Please advise on how to continue writing a test in integration/service/plugin_test.go when the goal should be to verify the task/container for the plugin has the correct environment variables set.

cpuguy83 · 2019-01-10T17:18:44Z

@sirlatrom You should be able to query the tasks API with the service ID as the filter.

sirlatrom · 2019-01-11T09:53:51Z

@cpuguy83 That works for regular Docker tasks, but the /tasks endpoint only returns tasks that have a ContainerSpec. So I can inspect the plugin service, since that endpoint does not hide plugin services, but I cannot get its tasks, because the tasks endpoint hides those.

sirlatrom · 2019-01-14T14:39:06Z

More specifically, it is this bit of code that restricts the runtime of the returned tasks:

moby/daemon/cluster/tasks.go

Lines 42 to 46 in 489b8ed


           if !filter.Contains("runtime") {

           	// default to only showing container tasks

           	filter.Add("runtime", "container")

           	filter.Add("runtime", "")

           }

I'll extend the test helper for task listing to allow additional filters, including the "runtime" filter.

sirlatrom · 2019-01-14T22:02:57Z

Flaky test is flaky. DockerHubPullSuite.TestPullFromCentralRegistry passed in experimental, powerpc and z, but failed on janky. DockerSuite.TestRunStoppedLoggingDriverNoLeak failed on windowsRS1.

sirlatrom · 2019-01-15T13:35:51Z

I force pushed to get checks to pass, but windowsRS1 still fails. @cpuguy83 Is that test unrelated? I feel like it is.

olljanat · 2019-01-15T17:23:24Z

(reserved for my derek commands)

plugin/defs.go

sirlatrom · 2019-03-27T11:09:18Z

Rebased on moby/moby master.

cpuguy83

LGTM

sirlatrom · 2019-03-27T23:08:04Z

Looks like experimental build fails because of this CRIU test, which I hope is unrelated:

Running /go/src/github.com/docker/docker/integration/container
INFO: Testing against a local daemon
=== RUN   TestCheckpoint
--- FAIL: TestCheckpoint (1.55s)
    checkpoint_test.go:40: Error (criu/util.c:816): exited, status=3
        Warn  (criu/net.c:2840): Unable to get socket network namespace
        Warn  (criu/net.c:2840): Unable to get tun network namespace
        Warn  (criu/sk-unix.c:229): unix: Unable to open a socket file: Bad address
        Warn  (criu/net.c:2840): Unable to get socket network namespace
        Warn  (criu/kerndat.c:881): Can't keep kdat cache on non-tempfs
        Looks good.
    checkpoint_test.go:51: Start a container
    checkpoint_test.go:69: ++ type -P true
        ++ type -P ip6tables-restore
        + mount --bind /bin/true /sbin/ip6tables-restore
        ++ type -P true
        ++ type -P ip6tables-save
        + mount --bind /bin/true /sbin/ip6tables-save
    checkpoint_test.go:81: Do a checkpoint and leave the container running
    checkpoint_test.go:24: Exec: [touch /tmp/test-file]
    checkpoint_test.go:28:
    checkpoint_test.go:115: Do a checkpoint and stop the container
    checkpoint_test.go:117: assertion failed: error is not nil: Error response from daemon: Cannot checkpoint container 1239a021c72845fc2ed944e75b6e41bf691bb2542b7f329aa9e09a76976cbf13: cannot checkpoint a stopped container: unknown
    checkpoint_test.go:77: ++ type -P ip6tables-restore
        + umount -c -i -l /sbin/ip6tables-restore
        ++ type -P ip6tables-save
        + umount -c -i -l /sbin/ip6tables-save
    main_test.go:32: assertion failed: error is not nil: Error response from daemon: Container 1239a021c72845fc2ed944e75b6e41bf691bb2542b7f329aa9e09a76976cbf13 is not paused: failed to unpause container 1239a021c72845fc2ed944e75b6e41bf691bb2542b7f329aa9e09a76976cbf13

The tests failing for z are TestCreateWithDuplicateNetworkNames and TestDockerNetworkConnectAlias, which I would also argue are unrelated.

I don't even know why the Windows tests are failing, but I'm hoping it's also unrelated.

Allow specifying environment variables when installing an engine plugin as a Swarm service. Invalid environment variable entries (without an equals (`=`) char) will be ignored. Signed-off-by: Sune Keller <[email protected]>

sirlatrom · 2019-04-12T16:32:16Z

@thaJeztah Any chance the "experimental" build could be retried?

thaJeztah · 2019-04-12T19:27:18Z

Restarted 👍

sirlatrom · 2019-04-13T10:43:28Z

Thanks @thaJeztah, looks like it passed the flaky tests this time 😅

Any chance the appropriate maintainers will give this their final judgement?

crosbymichael · 2019-07-08T19:26:44Z

LGTM
