Main Features

  • WebP or AVIF when supported by the device.
  • Detect Retina Displays (High Density) and loads images properly.
  • Automatically requests images with appropriate sizes based on your HTML/CSS definitions.
  • Responsive Images with img srcset and picture elements.
  • Background images support.

Setup

Add this snippet right between your <head> tag.

<link rel="preconnect" href="//img.imageboss.me">
<script type="text/javascript">
    window.ImageBoss = {
        source: 'mywebsite-images',
        // defaults
        devMode: false, // if currently your images are private set this to true to disable the library.
        format: 'auto', // use webp or avif when supported
        dpr: false // use dpr for your images when supported
    };
</script>
<script async src="//cdn.jsdelivr.net/gh/imageboss/[email protected]/dist/imageboss.min.js" type="text/javascript"></script>

Pre-connect

This is optional but can speed up the delivery of your images:

<link rel="preconnect" href="//img.imageboss.me">

Change your tags

Replace your <img /> tags from this (example):

<img src="myimage.jpg" width="150" />

to

<img
    data-imageboss-src="myimage.jpg"
    width="150"
/>
  • The transparent gif will help you validate your HTML and prevent the browser to load the default image “not found”.

Basic Usage

<img data-imageboss-src="" [attrs] />

You can use this library with the <img /> tags.

<div data-imageboss-bg-src="" [attrs] />

For background images use the property data-imageboss-bg-src="" instead. If you are defining your background on your CSS just remove the propery ´background-image´ from your CSS and use the html property data-imageboss-bg-src="" instead.

Advanced Usage

Lazy Loading

For lazy loading we recomend using it with lazy-sizes. All you have to do is set srcPropKey like this:

window.ImageBoss = {
    srcPropKey: 'data-src',
    srcsetPropKey: 'data-srcset',
    lowsrcPropKey: 'data-lowsrc',
    ...
};

And add the data-imageboss-class="lazyload" to your images. But feel free to check their docs in detail.

Low Quality Image Placeholder

If you are using lazy-sizes and want to display a low resolution image while the high one loads in background you can do it by changing the settings a bit:

window.ImageBoss = {
    srcPropKey: 'data-src',
    lowsrcPropKey: 'src',
    lowRes: true
    ...
};

Also, make sure to use data-imageboss-class instead of just class. This way we make sure we add the class only after the initialization.

For more options like animations and customizations on this behavior take a look into the lazy-sizes docs.

Responsive Images with srcset

If you just mention the sizes attribute, we will generate the breakpoints automatically for you.

<img
    data-imageboss-src="/path/to/my/image.jpg"
    sizes="(max-width: 500px) 100vw, 500px"
/>

The code above will generate the HTML:

<img
    src="https://img.imageboss.me/mysource/width/500/format:auto/path/to/my/image.jpg"
    sizes="(max-width: 500px) 100vw, 500px"
    srcset="
        https://img.imageboss.me/mysource/width/500/format:auto/path/to/my/image.jpg 500w,
        https://img.imageboss.me/mysource/width/250/format:auto/path/to/my/image.jpg 250w,
        https://img.imageboss.me/mysource/width/125/format:auto/path/to/my/image.jpg 125w,
        https://img.imageboss.me/mysource/width/750/format:auto/path/to/my/image.jpg 750w,
        https://img.imageboss.me/mysource/width/1125/format:auto/path/to/my/image.jpg 1125w,
        https://img.imageboss.me/mysource/width/1688/format:auto/path/to/my/image.jpg 1688w,
        https://img.imageboss.me/mysource/width/2531/format:auto/path/to/my/image.jpg 2531w,
        https://img.imageboss.me/mysource/width/3797/format:auto/path/to/my/image.jpg 3797w
    "
/>

If you want to specify the breakpoints yourself you can do it so:

<img
    data-imageboss-src="/path/to/my/image.jpg"
    data-imageboss-srcset="
        /path/to/my/image.jpg 100px,
        /path/to/my/image.jpg 300px
    "
    sizes="(max-width: 500px) 100vw, 500px"
/>

The code above will generate the HTML:

<img
    src="https://img.imageboss.me/mysource/width/500/format:auto/path/to/my/image.jpg"
    sizes="(max-width: 500px) 100vw, 500px"
    srcset="
        https://img.imageboss.me/mysource/width/100/format:auto/path/to/my/image.jpg 500w,
        https://img.imageboss.me/mysource/width/300/format:auto/path/to/my/image.jpg 250w
    "
/>

Responsive Images with picture

Similar to the how you would do with <img srcset ... />, just follow set the data-imageboss-srcset attribute on the source tags and the data-imageboss-src on the img tag.

<picture>
    <source media="(max-width: 1152px)" sizes="(max-width: 800px) 100vw,(max-width: 1152px) 50vw, 896px" data-imageboss-srcset="/path/to/my/image.jpg 512w">
    <source media="(max-width: 800px)" sizes="(max-width: 800px) 100vw,(max-width: 1152px) 50vw, 896px" data-imageboss-srcset="/path/to/my/image.jpg 800w">
    <img
        data-imageboss-src="/path/to/my/image.jpg"
    />
    </picture>

[attrs]

data-imageboss-source

In case you need to use a different source then the one mentioned globally.

<img
    data-imageboss-source="my-other-source"
    ...
/>

data-imageboss-low-res

When this option is enabled we will generate an attribute called data-lowres with a low resolution image that can be used for LQIP.

<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="cover"
    data-imageboss-cover-mode="face"
    data-imageboss-options="grayscale:true,blur:2"
    data-imageboss-low-res="true"
/>

data-imageboss-operation

It supports any of the operations available on: https://imageboss.me/docs

<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="width"
/>

data-imageboss-width

It's not necessary but can be helpful when you are displaying images with relative size. In order to detect the right width of your image we:

  • First look at the data-imageboss-width attribute,
  • Then, we look into the width HTML attribute.
  • Then, doesn't exist we look into the img.clientWidth size.
<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="width"
    data-imageboss-width="500"
/>

data-imageboss-height

It's not necessary but can be helpful when you are displaying images with relative size. In order to detect the right height of your image we:

  • First look at the data-imageboss-height attribute,
  • Then, we look into the height HTML attribute.
  • Then, doesn't exist we look into the img.clientHeight size.
<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="cover"
    data-imageboss-height="500"
/>

data-imageboss-cover-mode

For more options: https://imageboss.me/docs/operations/cover

<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="cover"
    data-imageboss-cover-mode="face"
/>

data-imageboss-options

Options can be any of those available for the operation you are trying to achieve. More information at: https://imageboss.me/docs

<img
    data-imageboss-src="/image.jpg"
    data-imageboss-operation="cover"
    data-imageboss-cover-mode="face"
    data-imageboss-options="grayscale:true,blur:2"
/>

data-imageboss-dpr

This is enabled by default for all elements. In case you don't want DPR for a specific image.

<img
    ...
    data-imageboss-dpr="false"
/>
