[kernel 3e/n] Decouple `CDBWrapper` and its kernel users from `ArgsManager` #25623

dongcarl · 2022-07-15T22:52:47Z

This is part of the libbitcoinkernel project: #24303, https://github.com/bitcoin/bitcoin/projects/18

This PR is NOT dependent on any other PRs.

This PR introduces ::Options structs and ApplyArgsManOptions functions for CDBWrapper and its wrappers and descendants in libbitcoinkernel. Namely CBlockTreeDB and CCoinsViewDB.

libbitcoinkernel code can now instantiate these classes by filling in an ::Options struct without referencing gArgs, and non-libbitcoinkernel code can use ApplyArgsManOptions with a local ArgsManager.

The ::Options struct and ApplyArgsManOptions duo has been used in many previous libbitcoinkernel ArgsManager decoupling PRs. See: https://github.com/bitcoin/bitcoin/projects/18

DrahtBot · 2022-07-16T01:40:00Z

The following sections might be updated with supplementary metadata relevant to reviewers and maintainers.

Conflicts

Reviewers, this pull request conflicts with the following ones:

#25862 (refactor, kernel: Remove gArgs accesses from dbwrapper and txdb by ryanofsky)
#25786 (refactor: Make adjusted time type safe by MarcoFalke)
#25781 (Remove almost all blockstorage globals by MarcoFalke)
#25704 (refactor: Remove almost all validation option globals by MarcoFalke)
#25665 (refactor: Add util::Result failure values, multiple error and warning messages by ryanofsky)
#24230 (indexes: Stop using node internal types and locking cs_main, improve sync logic by ryanofsky)
#23443 (p2p: Erlay support signaling by naumenkogs)
#22663 (dbwrapper: properly destroy objects in case CDBWrapper ctor throws by Crypt-iQ)

If you consider this pull request important, please also help to review the conflicting pull requests. Ideally, start with the one that should be merged first.

maflcko

1ed5723bc9c69bf2d7c2a902e44f3fc46b1165a7 🔶

Show signature

Signature:

src/dbwrapper.cpp

maflcko · 2022-07-18T11:37:57Z

src/txdb.cpp

2708fcb2accf4baae6652c7d5d9267550eff0c09: Why is this false?

This is a behavior change that I should probably document in the commit message. But I'd also like to hear if others think this is reasonable:

In my mind, options like wipe_existing and do_compact are "oneshot" parameters that should be latched to false after they've been applied for the first time. So in places like ResizeCache I think it makes more sense to supply false for these.

src/bench/checkblock.cpp

src/init.cpp

ryanofsky

Code review ACK 961c86a, but I think this would be better if the PR stopped adding ArgsManager::GetArg calls where they don't belong. I don't think there's a good reason to add new calls that will need to be deleted later from validation code when we can just delete them now. I know you aren't really concerned with indexing code, but I don't think it is great to add gArgs usages to indexing code either.

The main culprit here is gArgs.GetBoolArg("-forcecompactdb", false) calls and these can be eliminated by adding a node::ReadDatabaseArgs function analogous to the wallet::ReadDatabaseArgs function. I implemented this in f103f4d (tag) and also removed gArgs accesses from src/index/ code in the process

ryanofsky · 2022-07-20T21:09:41Z

src/dbwrapper.h

                .in_memory = fMemory,
                .wipe_existing = fWipe,
                .obfuscate_data = obfuscate,
+                .do_compact = gArgs.GetBoolArg("-forcecompactdb", false),


In commit "CDBWrapper: Pass in -forcecompactdb via ::Options" (d29f09a)

gArgs access doesn't really belong in dbwrapper.h header either

ryanofsky · 2022-07-20T21:10:56Z

src/index/base.cpp

+          .in_memory = f_memory,
+          .wipe_existing = f_wipe,
+          .obfuscate_data = f_obfuscate,
+          .do_compact = gArgs.GetBoolArg("-forcecompactdb", false),


In commit "Use CDBWrapper::Options ctor for non-test callers" (c5566d4)

Would be good not to add news gArgs calls here and below

ryanofsky · 2022-07-20T21:14:42Z

src/bitcoin-chainstate.cpp

        .chainparams = chainparams,
        .adjusted_time_callback = static_cast<int64_t (*)()>(GetTime),
+        .block_tree_db_opts = {
+            .db_path = gArgs.GetDataDirNet() / "blocks" / "index",


In commit "CBlockTreeDB: Add ::Options, init with BlockManager" (961c86a)

Should probably use abs_datadir variable, not gArgs

ryanofsky · 2022-07-20T21:19:36Z

src/txdb.cpp

+          .in_memory = fMemory,
+          .wipe_existing = fWipe,
+          .obfuscate_data = true,
+          .do_compact = gArgs.GetBoolArg("-forcecompactdb", false),


In commit "Use CDBWrapper::Options ctor for non-test callers" (c5566d4)

Moving gArgs.GetBoolArg("-forcecompactdb", false) call out of cdbwrapper code into txdb code seems like a step backwards or maybe sideways, since txdb code shouldn't be using ArgsManager either

dongcarl · 2022-07-21T20:34:30Z

@ryanofsky So I think we only add (net) 2 calls to gArgs, one in src/index/ and one in src/txdb. I plan to remove the one in src/txdb in the next PR, and add an ApplyArgsManOptions function to this PR so that it's easier to remove the reference in src/index/ in the future.

It is very difficult to maintain behavior and build-ability between commits without having to add oddly placed references to gArgs here and there (e.g. the one you pointed out in dbwrapper.h), since in order to correctly avoid the oddly placed gArgs references we'd have to bubble up the CDBWrapper::Options struct all the way to the top in a single commit. This would entail bubbling up both:

CDBWrapper::Options through CBlockTreeDB, through BlockManager, through ChainstateManager, to init (currently done in this PR)
CDBWrapper::Options through CCoinsViewDB, through CoinsViews, through InitCoinsDB (or, as I have it in my branch, through CChainState's constructor), through LoadChainstate, to init (to be done in the next PR)

in a single commit, which would likely be very hard to review. So we have to have some (admittedly awkward) resting points in these bubbling up chains just so that it's not a huge commit.

I do admit that I can do a better job of adding code comments so that it's clear these gArgs references are not meant to stay. I'd also welcome discussing alternative strategies that I might not be thinking of right now.

dongcarl · 2022-07-27T21:13:53Z

Push 961c86a -> ccdfad0aadc7c6424f9d1fff1ae7242c8eecb542

Add commits that also decouples CCoinsViewDB from ArgsManager
Reorganize commits

I've thought about it and perhaps it's best to do both CBlockTreeDB and CCoinsViewDB at once. This reduces the net addition of gArgs references to just the one instance in BaseIndex::DB::DB(...) and is probably less confusing to reviewers, see Ryan's review above.

This is not merge-able yet since ActivateSnapshot's call to std::unique_ptr<CChainState> does not take into account ArgsManager overrides. I will address this in a future push by adding a CCoinsViewDB::Options m_coinsdb_opts member to ChainstateManager.

dongcarl · 2022-08-04T23:00:20Z

When you pushed a big change and are waiting to see if the CI passes

2e79fb6 validation tests: Use existing {Chainstate,Block}Man (Carl Dong) Pull request description: This is split up because it is needed for two changes: * bitcoin/bitcoin#25781 * bitcoin/bitcoin#25623 ACKs for top commit: adam2k: ACK tested 2e79fb6 aureleoules: ACK 2e79fb6. Tree-SHA512: 2cd6a2fec19545f8ffc77e37ccb793aa6cb5815bb1b5e560c0345af6e0f890fd500ae3297b044d3f6f613b8dd7fd4553f5fc2824013342b9e25af1fe2b624967

maflcko · 2022-08-11T18:53:01Z

Could rebase after ##25815 ?

dongcarl · 2022-08-11T22:46:11Z

Push 60d3ffa118 -> 06bd11d505

Rebased over test: Use existing {Chainstate,Block}Man #25815
Updated PR description

The non-Options constructor is kept (it now calls the Options version of the constructor) so that we can fix callsites one-by-one without breaking builds, it will be removed later in this patchset.

Add an ApplyArgsManOptions function that currently just calls the ApplyArgsManOptions for CBlockTreeDB::Options. In a future commit in this patchset, this function will also call the ApplyArgsManOptions for CCoinsViewDB::Options.

Add a CBlockTreeDB::Options member to ChainstateManager::Options, and pass it down from ChainstateManager's ctor to BlockManager's ctor to CBlockTreeDB's new ctor that takes only a CBlockTreeDB::Options. This removes the need to reach into ChainstateManager -> BlockManager -> CBlockTreeDB right after you initialize the ChainstateManager, which was ugly. See node/chainstate.cpp and test/util/setup_common.cpp diffs. Notes: 1. In init.cpp, we needed to move the ChainstateManager initialization into the catch_exceptions block, otherwise exceptions thrown by the CBlockTreeDB ctor previously caught because they were in LoadChainstate would no longer be caught. 2. We also needed to add a data dir member to ChainstateManager::Options so that we can determine the default db_path for CBlockTreeDB if none is specified (See validation.h hunk). It does seem to make sense that ChainstateManager would know about what its data dir is anyway.

Since each BlockManager's m_block_tree_db will now be initialized with the BlockManager ctor, we don't need it to be a unique_ptr any more.

Add a CCoinsViewDB::Options member to ChainstateManager::Options, store it as a member in ChainstateManager's ctor, and pass it down to CChainState's ctor when CSM::{InitializeChainstate,ActivateSnapshot} is called. CChainState's ctor will then pass it down to CCoinsViews' new ctor that only takes a CBlockTreeDB::Options. This removes the need to call InitCoinsDB right after you construct your CChainState to have a working CChainState at all. In fact, CChainState::InitCoinsDB is entirely removed in this commit.

Since each CChainState's CoinsViewDB will now be initialized with the CChainState ctor, we don't need it to be a unique_ptr any more. Question for reviewers: Is deferring its destruction in Shutdown codepaths safe?

Also use scopes for freeing temporary CDBWrappers within tests.

Now that the non-Options constructor is no longer used anywhere, remove it.

Construct ChainstateManager with total_coinstip_cache so that we don't have to reach into it later in node::LoadChainstate to set it. Allows us to remove the CacheSizes parameter from node::LoadChainstate and the member from BasicTestingSetup. Done so in this commit.

ryanofsky

Tend to NACK. I think PR is doing some good things, but it is also doing some bad or questionable things. I think the main goal of the PR (decoupling txdb and dbwrapper from ArgsManager) can be achieved more simply. Would suggest starting from #25862 and building from there. Other changes in this PR if they are worth pursuing do not have to be done at the same time as removing ArgsManager calls.

The parts of the PR I think are good are:

Removing gArgs usages from txdb and dbwrapper.
Introducing a struct to group dbwrapper parameters.

The parts of this PR I think are bad are:

Making kernel API more complicated. The change makes bitcoin-chainstate.cpp example program harder to understand, and inappropriately exposes low level database settings (paths, obfuscation, cache size settings) to kernel applications that will mostly likely break if applications try to set them. I'm in favor of exposing low-level options, but not at cost of making simple applications harder to write. I also think this type of change should be done in a targeted PR, not as an accidental byproduct of internal refactoring.
Replacing a single GetBoolArg("-forcecompactdb") call in dbwrapper code, with 3 separate calls outside of it. This is layer violation exposing low-level database performance options to higher level application code. It also makes it unnecessarily difficult to add new debug/performance options because it now requires adding multiple struct fields and changing multiple layers of code.
Defining the overlapping fields in 3 different structs (DBWrapperOpts, BlockTreeDBOpts, CoinsViewDBOpts) and requiring boilerplate code to convert between struct types. There isn't a real justification for this complexity right now.

I think #25862 is a clean minimal change that does the work needed to make kernel code not depend on ArgsManager. There may be other changes in this PR that are worth keeping, but I don't think there's a reason to bundle them all together.

ryanofsky · 2022-08-17T06:02:50Z

src/init.cpp

+            },
+            .data_dir = gArgs.GetDataDirNet(),
+            .coins_view_db_opts = {
+                .cache_size = static_cast<size_t>(cache_sizes.coins_db), // FIXME


DrahtBot · 2022-08-22T10:38:12Z

🐙 This pull request conflicts with the target branch and needs rebase.

_{Want to unsubscribe from rebase notifications on this pull request? Just convert this pull request to a "draft".}

dongcarl · 2022-09-26T18:50:10Z

Closing in favor of #25862, lets get this done!
