snarkOS is a decentralized operating system for zero-knowledge applications. This code forms the backbone of Aleo network, which verifies transactions and stores the encrypted state applications in a publicly-verifiable manner.
The following snarkOS node types exist in the Aleo network:
- Validator: Validator nodes participate in consensus and must be started with an account that is bonded into the committee.
- Client: Clients do not participate in consensus but maintain a ledger. They are capable of providing information about the network as well as accepting solutions and transactions and communicating them to their peers. All clients run the same software, however, for the purposes of configuration management, this document defines two types of clients:
- Core Client: Client node connected directly to a validator node.
- Outer Client: Client node connected only to other clients or prover nodes.
- Prover: Prover nodes are dedicated to solving the Aleo puzzle. They do not participate in consensus or maintain a copy of the ledger.
The following are the requirements to run an Aleo node:
- OS: 64-bit architectures only, latest up-to-date for security
- Clients: Ubuntu 22.04 (LTS), macOS Ventura or later, Windows 11 or later
- Validators: Ubuntu 22.04 (LTS)
- CPU: 64-bit architectures only, Latest Intel Xeon or Better
- Clients: 24-cores (32-cores or larger preferred)
- Validators: 64-cores (128-cores or larger preferred)
- RAM: DDR4 or better
- Clients: 128GiB of memory (192GiB or larger preferred)
- Validators: 256GiB of memory (384GiB or larger preferred)
- Storage: PCIe Gen 3 x4, PCIe Gen 4 x2 NVME SSD, or better
- Clients: 2TB of disk space (4TB or larger preferred)
- Validators: 4TB of disk space (6TB or larger preferred)
- Network: Symmetric, commercial, always-on
- Clients: 250Mbps of upload and download bandwidth
- Validators: 500Mbps of upload and download bandwidth
No explicit recommendations are made for proving nodes as proving hardware may be highly variable. If interested in running Aleo Provers nodes, please refer to resources published by the Aleo community.
Before beginning, please ensure your machine has Rust installed, with at least this version. Instructions to install Rust can be found here.
Start by cloning this GitHub repository:
git clone --branch mainnet --single-branch https://github.com/ProvableHQ/snarkOS.git
Next, move into the snarkOS directory:
cd snarkOS
[For Ubuntu users] A helper script to install dependencies is available. From the snarkOS directory, run:
./build_ubuntu.sh
Lastly, install snarkOS:
cargo install --locked --path .
This CUDA build is optional. The current snarkOS puzzle does not leverage CUDA acceleration—it is a leftover from a previous event, although CUDA may become relevant again with ARC-43.
The CUDA feature is considered unstable and experimental; expect breaking changes.
For prover operators who want to experiment with GPU support:
cargo install --locked --path . --features cuda
Please ensure ports 4130/tcp and 3030/tcp are open on your router and OS firewall.
| Port | Protocol | Allow/Deny | Source | Explanation |
|---|---|---|---|---|
| 4130/tcp | TCP | Allow | All IPv4/IPv6 | TCP traffic to peers |
| Port | Protocol | Allow/Deny | Source | Explanation |
|---|---|---|---|---|
| 3030/tcp | TCP | Allow | All IPv4/IPv6 | REST server |
| 4130/tcp | TCP | Allow | All IPv4/IPv6 | TCP traffic to peers |
| Port | Protocol | Allow/Deny | Source | Explanation |
|---|---|---|---|---|
| 4130/tcp | TCP | Allow | All IPv4/IPv6 | TCP traffic to peers |
| 5000/tcp | TCP | Allow | Trusted Validator IPs | TCP traffic between validators for BFT communication |
| 3000/tcp | TCP | Allow | Internal VPC or VPN | Metrics dashboard, should only be open within an internal VPC or VPN |
| 3030/tcp | TCP | Deny | All IPv4/IPv6 | REST server. This should always be disabled for validators |
| 9000/tcp | TCP | Allow | Internal VPC or VPN | Metrics export, should only be open within an internal VPC or VPN |
| 9090/tcp | TCP | Allow | Internal VPC or VPN | Prometheus metrics, should only be open within an internal VPC or VPN |
Note: Ensure that your open file limit is set to 16,384 or above. For the recommended setting run:
# Increase the open file limit for the current user (replace <username> with your username)
echo "<username> - nofile 65536" | sudo tee -a /etc/security/limits.conf
# Increase the default system open file limit
sudo bash -c 'echo "DefaultLimitNOFILE=65536" >> /etc/systemd/system.conf'
Start by following the instructions in the Build Guide.
The guide below provides information on running core and outer clients (as defined in Section 2.2.) Aleo community members running validators are recommended to run 1-3 core clients as their exclusive client peers. This will ensure network traffic from the public internet is verified prior to reaching the validator.
Any client not connected directly to a validator can be considered an outer client.
The following command is recommended when starting a client node that is connected to a validator:
snarkos start --client --nodisplay --node 0.0.0.0:4130 --peers "validator_ip:4130,core_client_ip_1:4130,core_client_ip_2:4130,core_client_ip3:4130,outer_client_ip_1:4130,..." --verbosity 1 --norest
To start a core client node, you can also run the following command from the snarkOS directory:
./scripts/run-core-client.sh
The following command is recommended when starting a client node that is NOT connected to a validator:
snarkos start --client --nodisplay --node 0.0.0.0:4130 --peers "core_client_ip_1:4130,core_client_ip_2:4130,core_client_ip3:4130,outer_client_ip_1:4130,..." --verbosity 1 --rest 0.0.0.0:3030
To start an outer client node, you can also run the following command from the snarkOS directory:
./scripts/run-outer-client.sh
Outer clients can be bootstrap clients that serve as accessible entry points for new nodes joining the network with publicly known or static IPs.
For bootstrap clients, we also recommend the use of --rotate-external-peers to avoid the bootstrap peerlist from filling up.
Start by following the instructions in the Build Guide.
The following command is recommended when starting a validator node:
snarkos start --validator --nodisplay --bft 0.0.0.0:5000 --node 0.0.0.0:4130 --peers "validator_ip_1:4130,validator_ip_2:4130,...,core_client_ip_1:4130,core_client_ip_2:4130,..." --validators "validator_ip_1:5000,validator_ip_2:5000,..." --verbosity 1 --norest --private-key-file ~/snarkOS/privatekey
Instead of specifying a private key file (--private-key-file flag), the private key can also be defined explicitly (--private-key flag).
To start a validator, you can also run the following command from the snarkOS directory:
./scripts/run-validator.sh
Validator telemetry allows you to track participation in consensus. This is optional and can be enabled using the telemetry feature flag.
Once enabled, telemetry metrics are available through:
- Node logs
- REST API endpoints
// GET /{network}/validators/participation // GET /{network}/validators/participation?metadata={true}
You can enable telemetry in one of the following ways:
1. Enable via installation
Add the telemetry feature flag to the installation command.
cargo install --locked --path . --features telemetry
Run the ./scripts/run-validator.sh script and enable telemetry when prompted:
Do you want to enable validator telemetry? (y/n, default: y):
Start by following the instructions in the Build Guide.
Next, generate an Aleo account address:
snarkos account new
This will output a new Aleo account in the terminal.
Please remember to save the account private key and view key. The following is an example output:
Attention - Remember to store this account private key and view key.
Private Key APrivateKey1xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx <-- Save Me And Use In The Next Step
View Key AViewKey1xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx <-- Save Me
Address aleo1xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx <-- Save Me
Next, to start a proving node, from the snarkOS directory, run:
./scripts/run-prover.sh
When prompted, enter your Aleo private key:
Enter the Aleo Prover account private key:
APrivateKey1xxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxxx
- Ensure your machine has Rust installed, with at least this version. Instructions to install Rust can be found here.
- If large errors appear during compilation, try running
cargo clean. - Ensure
snarkOSis started using./scripts/run-client.shor./scripts/run-prover.sh.
- Ensure ports
4130/tcpand3030/tcpare open on your router and OS firewall. - Ensure
snarkOSis started using./scripts/run-client.shor./scripts/run-prover.sh.
- Before running the command above (
snarkos account new) trysource ~/.bashrc - Also double-check the spelling of
snarkos. Note the directory is/snarkOS, and the command issnarkos
- Generate an account with
snarkos account newif you haven't already - Sign a message with your private key using
snarkos account sign --raw -m "Message" --private-key-file=<PRIVATE_KEY_FILE> - Verify your signature with
snarkos account verify --raw -m "Message" -s sign1SignatureHere -a aleo1YourAccountAddress
Note, using the --raw flag with the command will sign plaintext messages as bytes rather than Aleo values such as 1u8 or 100field.
Ledger contains only public ledger information, while node-data contains information specific to the node that created it. The latter should not be shared with untrusted sources, and, for validators, contains data required to participate in consensus.
6. At startup I get an error telling me the nodes still uses the old storage format. What should I do?
The node should have created a new folder for the node data. For example, for mainnet a folder should exist at ~/.aleo/storage/node-data-0.
The error message will tell you what data to migrate. Alternatively, you can start the node with --auto-migrate-node-data and it will attempt to do this automatically.
The following is an overview of all files that may be needed to be migrated.
- The JSON Web token secret, located at
~/.aleo/storage/jwt_secrect_{address}.txt. Move it to~/.aleo/storage/node-data-0/jwt_secret_{address}.txt. Note, if you are running different nodes with different addresses there may be multiple of these. The error message will tell you which one to migrate. - The router peer cache located at
~/.aleo/storage/ledger-0/cache_router_peers. Migrate it to~/.aleo/storage/node-data-0/router-peer-cache. - The gateway peer cache located at
~/.aleo/storage/ledger-0/cache_gateway_peers(only for validators). Migrate it to~/.aleo/storage/node-data-0/gateway-peer-cache. - The latest proposal cache located at
~/.aleo/storage/current-proposal-cache-0(only for validators). Migrate it to~/.aleo/storage/node-data-0/current-proposal-cache.
To run a node with custom settings, refer to the options and flags available in the snarkOS CLI.
The full list of CLI flags and options can be viewed with snarkos --help:
snarkOS
The Aleo Team <[email protected]>
USAGE:
snarkos [OPTIONS] <SUBCOMMAND>
OPTIONS:
-h, --help Print help information
-v, --verbosity <VERBOSITY> Specify the verbosity [options: 0, 1, 2, 3] [default: 2]
SUBCOMMANDS:
account Commands to manage Aleo accounts
clean Cleans the snarkOS node storage
help Print this message or the help of the given subcommand(s)
start Starts the snarkOS node
update Update snarkOS
The following are the options for the snarkos start command:
--network <NETWORK>
Specify the network ID of this node [options: 0 = mainnet, 1 = testnet, 2 = canary]
[default: 0]
--prover
Start the node as a prover
--client
Start the node as a client (default).
Client are "full nodes", i.e, validate and execute all blocks they receive, but they do not participate in AleoBFT consensus.
--bootstrap-client
Start the node as a bootstrap client.
--validator
Start the node as a validator.
Validators are "full nodes", like clients, but also participate in AleoBFT.
--noupdater
Disable checking for new versions at startup
--private-key <PRIVATE_KEY>
Specify the account private key of the node
--private-key-file <PRIVATE_KEY_FILE>
Specify the path to a file containing the account private key of the node
--node <NODE>
Set the IP address and port used for P2P communication
--bft <BFT>
Set the IP address and port used for BFT communication. This argument is only allowed for validator nodes
--peers <PEERS>
Specify the IP address and port of the peer(s) to connect to (as a comma-separated list).
These peers will be set as "trusted", which means the node will not disconnect from them when performing peer rotation.
Setting peers to "" has the same effect as not setting the flag at all, except when using `--dev`.
--validators <VALIDATORS>
Specify the IP address and port of the validator(s) to connect to
--rest <REST>
Specify the IP address and port for the REST server
--rest-rps <REST_RPS>
Specify the requests per second (RPS) rate limit per IP for the REST server
[default: 10]
--jwt-secret <JWT_SECRET>
Specify the JWT secret for the REST server (16B, base64-encoded)
--jwt-timestamp <JWT_TIMESTAMP>
Specify the JWT creation timestamp; can be any time in the last 10 years
--norest
If the flag is set, the node will not initialize the REST server
--nojwt
If the flag is set, the node will not require JWT authentication for the REST server
--trusted-peers-only
If the flag is set, the node will only connect to trusted peers and validators
--nodisplay
Write log message to stdout instead of showing a terminal UI.
This is useful, for example, for running a node as a service instead of in the foreground or to pipe its output into a file.
--verbosity <VERBOSITY>
Specify the log verbosity of the node. [options: 0 (lowest log level) to 6 (highest level)]
[default: 1]
--log-filter <LOG_FILTER>
Set a custom log filtering scheme, e.g., "off,snarkos_bft=trace", to show all log messages of snarkos_bft but nothing else
--logfile <LOGFILE>
Specify the path to the file where logs will be stored
[default: /var/folders/6v/1bwnpyjd1r5f9wr_9hq25qsm0000gn/T/snarkos.log]
--metrics
Enable the metrics exporter
--metrics-ip <METRICS_IP>
Specify the IP address and port for the metrics exporter
--ledger-storage <LEDGER_STORAGE>
Specify the directory that holds all ledger data, e.g., blocks and transactions.
This flag overrides the default path, even when `--dev` is set.
The old name for this flag (`--storage`) is DEPRECATED and will eventually be removed.
--node-data-storage <NODE_DATA_STORAGE>
Specify the directory that holds node-specific data, that is not part of the global ledger.
This flag overrides the default path, even when `--dev` is set.
That folder may contain sensitive data, such as the JWT secret, and should not be shared with untrusted parties.
For validators, it also contains the latest proposal cache, which is required to participate in consensus.
--cdn <CDN>
Enables the node to prefetch initial blocks from a CDN
--nocdn
If the flag is set, the node will not prefetch from a CDN
--dev <DEV>
Enables development mode used to set up test networks.
The purpose of this flag is to run multiple nodes on the same machine and in the same working directory.
To do this, set the value to a unique ID within the test work. For example if there are four nodes in the network, pass `--dev 0` for the first node, `--dev 1` for the second, and so forth.
If you do not explicitly set the `--peers` flag, this will also populate the set of trusted peers, so that the network is fully connected.
Additionally, if you do not set the `--rest` or the `--norest` flags, it will also set the REST port to `3030` for the first node, `3031` for the second, and so forth.
--dev-num-validators <DEV_NUM_VALIDATORS>
If development mode is enabled, specify the number of genesis validator
[default: 4]
--dev-num-clients <DEV_NUM_CLIENTS>
If development mode is enabled, specify the number of clients. This is only used by validators to automatically populate their set of trusted peers.
This option cannot be used while also passing the `--peers` flag.
--no-dev-txs
If development mode is enabled, specify whether node 0 should generate traffic to drive the network
--dev-bonded-balances <DEV_BONDED_BALANCES>
If development mode is enabled, specify the custom bonded balances as a JSON object
-h, --help
Print help (see a summary with '-h')
In the first terminal, start the first validator by running:
cargo run --release -- start --nodisplay --dev 0 --validator
In the second terminal, start the second validator by running:
cargo run --release -- start --nodisplay --dev 1 --validator
In the third terminal, start the third validator by running:
cargo run --release -- start --nodisplay --dev 2 --validator
In the fourth terminal, start the fourth validator by running:
cargo run --release -- start --nodisplay --dev 3 --validator
From here, this procedure can be used to further start-up provers and clients.
It is important to initialize the nodes starting from 0 and incrementing by 1 for each new node.
The following is a list of options to initialize a node (replace <NODE_ID> with a number starting from 0):
cargo run --release -- start --nodisplay --dev <NODE_ID> --validator
cargo run --release -- start --nodisplay --dev <NODE_ID> --prover
cargo run --release -- start --nodisplay --dev <NODE_ID> --client
cargo run --release -- start --nodisplay --dev <NODE_ID>
When no node type is specified, the node will default to --client.
To run a local devnet with the script, start by installing tmux.
macOS
To install tmux on macOS, you can use the Homebrew package manager.
If you haven't installed Homebrew yet, you can find instructions at their website.
# Once Homebrew is installed, run:
brew install tmuxUbuntu
On Ubuntu and other Debian-based systems, you can use the apt package manager:
sudo apt update
sudo apt install tmuxWindows
There are a couple of ways to use tmux on Windows:
- First, install Windows Subsystem for Linux.
- Once WSL is set up and you have a Linux distribution installed (e.g., Ubuntu), open your WSL terminal and install
tmuxas you would on a native Linux system:
sudo apt update
sudo apt install tmuxTo start a local devnet, run:
./scripts/devnet.sh
Follow the instructions in the terminal to start the devnet.
To toggle to the next node in a local devnet, run:
Ctrl+b n
To toggle to the previous node in a local devnet, run:
Ctrl+b p
To select a node in a local devnet, run:
Ctrl+b w
To select a node manually in a local devnet, run:
Ctrl+b :select-window -t {NODE_ID}
To stop a local devnet, run:
Ctrl+b :kill-session
Then, press Enter.
To clean up the node storage, run:
cargo run --release -- clean --dev <NODE_ID>
By default, the metrics feature is turned on for some internal crates.
- history - Enables a /history REST endpoint.
- telemetry - Allows the node to upload telemetry data.
- cuda - Allows some operations to run on the (NVidia) GPU, instead of on the CPU. See CUDA acceleration for provers for install tips and current puzzle status.
- locktick - This feature turns on code for detecting deadlocks.
- test_targets - This feature allows the lowering of coinbase and proof targets for testing.
The snarkOS node implementation uses rocksdb under the hood. By using its native checkpointing mechanism, you can create backups locally and efficiently. The backups leverage hard links on your filesystem, thereby incurring only a marginal amount of extra space. The aim of these local backups is for you to be able to recover quickly in case your node were to halt.
You can find a basic sample script in scripts/backup.sh which you can run as a cron-job e.g. every minute. Each run of the script creates a new backup folder with a timestamp postfix. It will ensure a backup is kept which is 1 minute old, 5 minutes old, 1 hour old and 1 day old. In more detail, on each run it will:
- always overwrite the latest backup
- only overwrite the 5 minute backup if it is older than 5 minutes
- only overwrite the 1 hour backup if it is older than 1 hour
- only overwrite the 1 day backup if it is older than 1 day
You may want to change the NETWORK, BASE_DIR, ENDPOINT and JWT variables.
Thank you for helping make snarkOS better!
🧐 What do the emojis mean?
This project follows the all-contributors specification. Contributions of any kind are welcome!
We welcome all contributions to snarkOS. Please refer to the license for the terms of contributions.
![@dependabot[bot]](https://avatars.githubusercontent.com/in/29110?s=64&v=4){kind=small}
![@dependabot-preview[bot]](https://avatars.githubusercontent.com/in/2141?s=64&v=4){kind=small}
